Klüberoil 4 UH1-100 N Synthetic gear and multipurpose oil for the food-processing and pharmaceutical industries | N° 029040
  • A synthetic high-performance gear and multipurpose oil based on polyalphaolefin satisfying the growing requirements and increasing power density of modern gears.
  • Based on high-grade raw materials and advanced additives, enabling maximum performance in the lubrication of all gear components.
  • Volume: 5L
Benefits for your application
  • Registered as NSF H1 and certified according to ISO 21469
  • High scuffing protection
  • Good wear protection for gears and rolling bearings
  • Good shear stability for reliable lubricant film formation
  • Excellent ageing and oxidation resistance
  • Wide service temperature range due to good viscosity-temperature behaviour
  • Low foaming tendency
  • Energy savings due to optimised friction behaviour
  • Good elastomer compatibility
  • Approved by numerous gear OEMs

Application

  • Klüberoil 4 UH1 N was developed for the lubrication of spur, bevel and worm gears subject to high loads, bearings, spindles, joints as well as lifting, drive and transport chains.
  • Klüberoil 4 UH1 N is registered as NSF H1 for use in the food-processing and pharmaceutical industries and complies with FDA 21 CFR Sec 178.3570.
  • It was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries.

Application notes

  • Klüberoil 4 UH1 N can be used for immersion, immersion circulation and injection lubrication.
  • The use of drip-feed oilers, brushes, oil cans or suitable automatic lubricating systems is also possible.
  • When using automatic lubricating systems, please note the manufacturer's instructions regarding the maximum permissible viscosity.
  • The low-viscosity varieties are also used for oil mist lubrication.
Technical specifications
 NSF-H1 registration 121 173
 Upper service temperature 120 °C / 248 °F
 Density, based on DIN 51757) at 15 °C approx. 855 kg/m³
 Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C approx. 100 mm²/s
 Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C approx. 14 mm²/s
 ISO viscosity grade, DIN ISO 3448 100
 Viscosity index, DIN ISO 2909 >= 140
 Foam test, ASTM-D 892, ISO 6247, sequence I/24 °C <= 100/10 ml
 Foam test, ASTM-D 892, ISO 6247, sequence II/ 93.5 °C <= 100/10 ml
 Foam test, ASTM D 892, ISO 6247, sequence III/24°C <= 100/10 ml
 Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus >= 200 °C
 Pour point, DIN ISO 3016 <= -36 °C
 Ageing properties, ASTM D 2893, increase in viscosity <= 6 %
 Copper corrosion, DIN EN ISO 2160, 24 h/100°C 1 - 100 corrosion degree
 Anticorrosive properties on steel, DIN ISO 7120, method A, steel, 24 h/60 °C no rust corrosion degree
 FZG scuffing test, DIN ISO 14635-1, A/8.3/90, scuffing load stage >= 12
 FAG FE8 rolling bearing test, DIN 51819-3, D 7,5/80-80, wear of rolling element <= 30 mg
 FAG FE8 rolling bearing test, DIN 51819-3, D 7,5/80-80, wear of cage <= 200 mg
 Minimum shelf life from the date of manufacture - in a dry, frost-free place and in the
 unopened original container, approx.
 24 months



Property GTIN/EAN MPN (Manufacturer Part Number)
- 0725175308248 943151122
