WEICONLOCK AN 305-86 Pipe Sealant high-strength red 20ml pen

WEICONLOCK AN 305-86 Pipe Sealant high-strength red 20ml pen

pics/Weicon/AN 305-86/weiconlock-an-305-86-high-strength-pipe-sealant-red-20ml-pen-01.jpg

€ 16.6 16.60 incl. VAT (13.95 excl. VAT), per piece *

Availability: Available

Packaging unit: 1 piece

More…

Manufacturer: Weicon

Country of origin: DE/0004

Customs tariff number: 35061000

Weight per piece: 50 g

Recommend this product

Questions about the product

The product description does not help you?
No problem. Simply fill out the form and we will answer you as soon as possible.

Questions about the product

Title ×

Mr. Ms.

First name ×

Last name ×

e-mail ×

Telephone

Message ×

The fields marked with (×) are required.

Security (ANTI-SPAM)

three + two = ?

( Examples: two + three = 5, three - five = -2 )

WEICONLOCK AN 305-86 is an extra strong, high viscosity pipe and thread sealing adhesive designed for permanent, high-strength joints that are difficult to disassemble. Suitable for sealing threaded pipe connections up to M56 / R2".

Pack size: 20 ml Pen
Also available in: 50 ml, 200 ml

Applications

Extra strong pipe sealing and thread locking
Permanent, high-strength joints
Resistant to high pressures and temperatures

Features

High viscosity (6,000 – 7,000 mPa·s)
Gap bridging up to 0.3 mm
High shear strength (10 – 20 N/mm²)
Handling strength: 60–90 min, final strength 12–24 h
Temperature resistance: −60 °C to +150 °C
Complies with MIL-S-46163 A Type I Grade L

Technical specifications

Colour	Red
Fluorescent	No
Thread size	Up to M56 / R2"
Viscosity	6,000 – 7,000 mPa·s
Gap bridging	Up to 0.3 mm
Breakaway torque	15 – 30 Nm
Prevail torque	25 – 45 Nm
Shear strength	10 – 20 N/mm² (DIN 54452)
Handling strength	60 – 90 min (RT)
Final strength	12 – 24 h
Temperature resistance	−60 °C to +150 °C
Max. pressure resistance (M3–M10)	500 – 1500 bar

Storage

Shelf life: 24 months at room temperature (+20 °C) in unopened container

Hazard information (CLP)

Signal word: Warning

Hazard pictogram(s):

GHS07

Hazard statements (H-statements)

H315 – Causes skin irritation.
H317 – May cause an allergic skin reaction.
H319 – Causes serious eye irritation.
H335 – May cause respiratory irritation.

Precautionary statements (P-statements)

Prevention:

P280 – Wear protective gloves. Wear eye or face protection.
P271 – Use only outdoors or in a well-ventilated area.
P261 – Avoid breathing vapor.
P264 – Wash thoroughly after handling.

Response:

P304 + P312 – IF INHALED: Call a POISON CENTER or doctor if you feel unwell.
P362 + P364 – Take off contaminated clothing and wash it before reuse.
P302 + P352 – IF ON SKIN: Wash with plenty of water.
P333 + P313 – If skin irritation or rash occurs: Get medical advice/attention.
P305 + P351 + P338 – IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
P337 + P313 – If eye irritation persists: Get medical advice/attention.

Storage:

P405 – Store locked up.
P403 + P233 – Store in a well-ventilated place. Keep container tightly closed.

Disposal:

P501 – Dispose of waste according to applicable legislation.

Information on product safety (Manufacturer, Contact)

WEICON GmbH & Co. KG, Königsberger Strasse 255, 48157 Münster, GERMANY, +49 251 9322-0, [email protected], www.weicon.de

weiconlock-an-305-86-high-strength-pipe-sealant-tds-datasheet.pdf (219.93 KB)
